Outdoor High Brightness Monitor
High Brightness
Outdoor Touch Monitor
High Brightness
Outdoor Touch Monitor
Our ETH series high brightness touch monitor is for outdoor application. is industrial grade solution with sun-readable display, designed with aluminum cover, size range from 10.1” to 43”. IP65 Protection degree. clarifying image quality with versatile of installation method, Custom services are available for the specific projects, that’s perfect solution for outdoor videos, Airport, bus ,rail station, Museums and visitor displays.
INTERFACE
HDMI
DVI
VGA
SPECIFICATION
|
Name
|
: High Brightness Outdoor Open Frame Touchscreen Monitor
|
|
LCD Size
|
: 7"-65" TFT LCD
|
|
Resolution
|
:1024*768 to 1920*1080
|
|
Brightness
|
: 250 to 15000 cd/m^2
|
|
Contract Ratio
|
: 1000:1
|
|
Response Time
|
: ≤12ms
|
|
View Angle
|
: 89/89/89/89/ IPS
|
|
Touch Screen
|
: Resistive Touchscreen / PCAP Touchscreen
|
|
Touch Accuracy
|
: <2mm
|
|
Touch Transmittance
|
: >85%
|
|
Touch Input
|
: Finger, Glove, etc
|
|
Interface
|
: VGA+USB Touch+HDMI
|
|
Power Supply
|
: AC 110V-220V DC 12V
|
|
OS
|
: Win XP, Win 7, Win 8, Win CE, Android, Linux, Mac
|
|
Working Environment
|
: 0 to 60 Degree Celcius | Relative Humidity 5%-90% (non-condencing)
|
|
Sotrage Temperature
|
: -20 to 70 Degree Celcius (storage)
|
|
Case Mounting
|
: Vesa, Wall Mount, Embedded
|
|
Certificate
|
: CE FCC
|
APLICATIONS
Parking
Outdoor Videos
Airport
Bus
FEATURES
Multi Touch Available
PCAP touchscreen 10 point accurate touch, support multi gesture.
Rugged Monitor 7/24 Running
Pure flat surface with aluminium fram, IP65 protection degree, with industrial degreed components support 0-50 degrees and -20 to 70 degrees as working temperature. With the 24 hours 7 days continuous stable working capacity.
Sun-Readable
1500 cd/m^2 brightness, hihg brightness display, readable under sun.
High Brightness Outdoor Touch Screen
| PART NUMBER | SIZE | Resolution | Brightness /cd/m² | Contract | View angle | interface | Touch Type |
|---|---|---|---|---|---|---|---|
|
ETH101OD001
|
10.1"
|
1366*768
|
1000
|
500:1
|
85/85/85/85 (Typ.)(CR≥10)
|
VGA+DVI+HDMI
|
resistive /pcap touch screen
|
|
ETH1040D001
|
10.4"
|
1024*768
|
1000
|
900:1
|
75/75/75/75 (Typ.)(CR≥10)
|
VGA+HDMI VGA+DVI
|
resistive /pcap touch screen
|
|
ETH1210D001
|
12.1"
|
1024*768
|
1000
|
700:1
|
80/80/80/80 (Typ.)(CR≥10)
|
VGA VGA+HDMI VGA+DVI
|
resistive /pcap touch screen
|
|
ETH1500D001
|
15"
|
1366*768
|
1500
|
700:1
|
80/80/60/80 (Typ.)(CR≥10)
|
VGA VGA+HDMI VGA+DVI
|
resistive /pcap touch screen
|
|
ETH1560D001
|
15.6"
|
1920*1080 /1366*768
|
1000/1500
|
700:1
|
80/80/70/70(Typ.)(CR≥10)
|
VGA VGA+HDMI VGA+DVI
|
PCAP touch screen
|
|
ETH1700D001
|
17"
|
1280*1024
|
1500
|
1000:1
|
85/85/80/80 (Typ.)(CR≥10)
|
VGA VGA+HDMI VGA+DVI
|
resistive /pcap touch screen
|
|
ETH1900D001
|
19"
|
1280*1024/1440*900
|
1500
|
1000:1
|
85/85/80/80 (Typ.)(CR≥10)
|
VGA VGA+HDMI VGA+DVI
|
resistive /pcap touch screen
|
|
ETH2150D001
|
21.5"
|
1920*1080
|
1500
|
1000:1
|
89/89/89/89(Typ.)(CR≥10)
|
VGA VGA+HDMI VGA+DVI
|
PCAP touch screen
|
|
ETH236OD001
|
23.6"
|
1920*1080
|
1500
|
1000：1
|
89/89/89/89(Typ.)(CR≥10)
|
VGA VGA+HDMI VGA+DVI
|
PCAP touch screen
|
|
ETH270OD001
|
27"
|
1920*1080
|
2000
|
1000:1
|
89/89/89/89(Typ.)(CR≥10)
|
VGA VGA+HDMI VGA+DVI
|
PCAP touch screen
|
|
ETH3200D001
|
32"
|
1920*1080
|
3000
|
1000:1
|
89/89/89/89(Typ.)(CR≥10)
|
VGA+HDMI
|
PCAP touch screen
|
|
ETH430OD001
|
43"
|
1020*1080
|
3000
|
1000:1
|
89/89/89/89(Typ.)(CR≥10)
|
VGA+HDMI
|
PCAP touch screen
|
Lets Start Something
Great Together
for a professional advise and a free quote . Eagle Touch will be always your touch and display expert.
